| Place of Origin: | CHINA PDC die cast machine supplier manufacturer |
|---|---|
| Brand Name: | HD, LZ |
| Certification: | CE |
| Model Number: | 150-500t 12t 20t 30t |
| Minimum Order Quantity: | 1SET |
| Packaging Details: | STEEL BOX |
| Delivery Time: | 30-40DAYS |
| Payment Terms: | T/T |
| Supply Ability: | 300SETS/YEAR |
| Usage: | Pressure Die Cast | Material: | Aluminum, Magnesium, Copper, Zinc, Zamak, Lead |
|---|
PDC machine(Pressure Die Casting Machine),HPDC machine(High pressure die casting machine).
Pressure die casting machines (PDC machines)are used to produce metal parts with high accuracy, consistency, and speed. These machines use a high-pressure injection system to force molten metal into a die or mold cavity, where it solidifies and takes the shape of the cavity. The resulting parts are strong, precise, and often require little or no additional machining.
There are two maintypes of pressure die casting machines:Hot chamber machinesandCold chamber machines.
Hot chamber machinesare used for metals with low melting points, such asZAMAK/Zinc, Lead/PB, and Tin alloy. The metal is melted in a furnace that is attached to the machine and then injected into the mold.
Cold chamber machines, are used for metals with high melting points( low melting point alloies are also allowed), such asCopper, Brass, and Aluminum, Magnesium, Zamak/Zinc, Lead/Pballoy. In this type of machine, the molten metal is poured into a separate chamber and then injected into the mold.
Some common features ofPDC Machines(pressure die casting machines) include a hydraulic system to control the pressure, a casting chamber, and a mold. The mold is typically made of steel and is designed to produce the desired shape of the part being manufactured. The casting chamber is where the molten metal is injected into the mold under high pressure.
The basic components of apressure die casting machineinclude the injection system, the die or mold, and the clamping system. The injection system typically consists of a metal melting furnace, a shot chamber, and a plunger. The metal is melted in the furnace and then transferred to the shot chamber, where it is injected into the die cavity under high pressure.
Thedie casting dieormoldis made of two halves, which are closed and clamped together during the casting process. The clamping system provides the necessary force to keep the two halves of the die or mold together during the injection and solidification process. Once the part has solidified, the die is opened and the finished part is ejected.
Pressure die casting machinescan produce parts from a variety of metals, including aluminum, magnesium, lead, brass, copper, and zinc. They are commonly used in the automotive industry to produce engine components, transmission parts, and other critical components. They are also used in the aerospace industry to produce complex parts for aircraft and spacecraft. Other industries that rely on pressure die casting machines include electronics, appliances, and medical equipment.
KYLT Industrial is your trustablePDC machines(PressureDie casting machines) manufacturer& supplier & factory.ForPDC machines price&die casting molds prices,please Email us:cnkylt@aliyun.com
