full automatic 22T PLC zinc lead injection machine

Basic Information
Place of Origin: china
Brand Name: LT
Model Number: 12T.18T.20T.22T.30T
Packaging Details: WOODEN BOX
Delivery Time: 45DAY
Payment Terms: TT
Contact Now
High Light:

zinc inject


aluminum inject


alu die cast


Full automatic 22T PLC zinc lead injection machine:


Die locking force:220KN

Tie-bars dia.:40MM

Die stroke: 130MM

Tie bars space:232*278MM

Mold thickness:150-220MM

Max.injection force: 21KN

Ejection force:13KN

Flow rate of oil pump:31L/min

Working oil pressure:6-7Mpa

Output of pump motor:5.5/6Kw/P

Melting pot capacity(Zn.):120KG

Accumulator capacity:10L

Oil tank capacity:200L

Input of furnace heating:9KW

Machine weight : 2.0T

Machine size: 3000*980*1700MM

(PLC control system can be used.)

KYLT 22T PLC Zinc injection machine,also named, 22T zinc(Zn.) hot chamber casting machine, zinc metal injection machine,or metal casting machine, zipper casting /injection machine.

Other we have12T,18T,20T,30Thot chamber die casting machines for our client to choose.Those machines can be used to cast, zinc(Zn. or Zamark), lead(Pb.), Tin alloy etc low melting point materials.
Main used to cast:zinc auto parts, zinc zipper head and puller,zinc spoon, coin, lable, logo, jewelry, battery lead(Pb.) bushing and terminal etc.
